Feedback – Yes
Standard Feedback Voltage - 24 VDC12 VDC 24
VDC Stroke - 8 inch
Force - 2000 lbs.
Force, Speed & Current
|
Voltage |
12 VDC |
24VDC |
|
Dynamic Force |
2000 lbs |
2000 lbs |
|
Static Force |
4000 lbs |
4000 lbs |
|
Speed - No Load |
0.33"/sec |
0.33"/sec |
|
Speed - Full Load |
0.27"/sec |
0.27"/sec |
|
Current - No Load |
3.5 A |
1.8 A |
|
Current - Full Load |
20.0 A |
10.0 A |
Input Voltage:
12 VDC, 24VDC
Stroke:
1" to 24"
Features:
Cost Effective, Powerful, Heavy Duty, High Protection
Feedback:
Yes
Duty Cycle:
25%
Weather Protection:
IP65
Overload Protection:
Mechanical Slip Clutch
Operational Temperature:
-25°C to 65°C
Operating Noise:
<70 dBA
Limit Switch:
Built-In (Adjustable)
Cable Length:
40"
Connector:
Tinned Wire Leads
Front Mounting Hole Size:
0.50"
Rear Mounting Hole Size:
0.50"
Actuator Type:
Industrial
Motor Type:
Brushed DC Motor
Screw Type:
ACME
Stroke Rod Material:
Stainless Steel 304
Housing Material:
Stainless Steel
Gear Material:
Powder Metallurgy Steel Alloy
Certifications:
CE, RoHS
Compatible Mounting Brackets:
BRK-17
Control Boxes Compatibility
Model
Subcategory
Control Boxes Compatibility
Integration Requirements
PA-17-POT
Input 12 or 24 VDC
None
Comes with a built-in potentiometer for reading positional feedback. Please pay attention to the current draw and refer to the product datasheet of each model for the voltage and current rating. For more information, feel free to contact our team of engineers and we'll be happy to assist you.
